Display

Custom designed monochrome, Transflective "Black on white" full graphics display, resolution 128 x 32 pixels. Backlit with white LEDs.

Case

Full custom designed injection moulded in black ABS, fully sealed

Connections

Single 9-way d-type, for serial communications and power for diection connection to a DL1 data logger

Power supply

Requires 12v at approximately 100mA

Processor

C2000 series 32 DSP running at 150MHz. Internal Flash for program and configuration storage.

Temperature range

Operation between 0oC to 50oC, limited by the LCD display. Storage from -20oC to 80oC.

LEDs

High brightness 3mm LEDs. 20 degree viewing angle. 10 steps of brightness control.

Membrane keypad

Polyester textured membrane to limit reflections. Buttons 12mm and 15mm diameter.
