SEAT
Supported Models
- Seat Ibiza 3rd series 2003-2008
- Seat Ibiza 4th series from 2008
- Seat Leon 1st series 2000-2005
- Seat Leon 2nd series 2005-2012
Connections
Race Technology CAN connections
Audi CAN connection cables can be found in different places: behind the instrument cluster, near the steering column, behind the fuse box or the glove box inside the main wiring loom. Regardless of the stock ECU installed on the car, colours of the cables you need to connect to are always the same, they are twisted
CAN low - Orange/brown
CAN High - Orange/black
ECU setup
No ECU setup or termination is required.
Channel listing – CAN interface
| ECU Name
| Race Technology message
| Race Technology Default name
| Race Technology VAR number
| Resolution
|
| ECU_RPM
| RPM
| RPM
| VAR_0010
| 1 RPM
|
| ECU_SPD1
| misc 4
| Speed from the ECU
| VAR_4003
| 0.1 km/h
|
| ECU_WATERTMP
| temperature 8
| coolant temp
| VAR_1007
| 1c
|
| ECU_AIRTEMP
| temperature 2
| Inlet pre turbo 1
| VAR_1001
| 1c
|
| ECU_ATMTEMP
| temperature 3
| Inlet pre turbo 2
| VAR_1002
| 1c
|
| ECU_FUEL
| Aux 3
| Lambda 2 short trim
| VAR_2002
| raw value
|
| ECU_GEAR
| Aux 13
| Fuel inj 8 PW
| VAR_2012
| raw value
|
| ECU_ENGOILT
| temperature 9
| Oil temp
| VAR_1008
| 1c
|
| ECU_TPS
| Aux 1
| Throttle position
| VAR_2000
| 0.10%
|
| ECU_BOOST_TFSI
| pressure 5
| Boost pressure
| VAR_3504
| 1kpa
|
| ECU_FUEL_P_L
| pressure 3
| Fuel pressure
| VAR_3502
| 0.1 bar
|
| ECU_FUEL_P_H
| pressure 4
| coolant pressure
| VAR_3503
| 0.1 bar
|
| ECU_LAMBDA
| misc 1
| Lambda 1
| VAR_4000
| 0.001
|
| ECU_ERR_CODE
| Aux 32
| Auxiliary 32
| VAR_2031
| raw value
|
| ECU_RT_BOOST
| Aux 33
| Auxiliary 33
| VAR_2032
| raw value
|
Channel listing – DL1/DASH2 PRO direct CAN
| ECU Name
| Race Technology message
| Race Technology Default name
| Race Technology VAR number
| Resolution
|
| ECU_RPM
| RPM
| RPM
| VAR_0010
| 1 RPM
|
| ECU_SPD1
| misc 4
| Speed from the ECU
| VAR_4003
| 0.1 km/h
|
| ECU_WATERTMP
| temperature 8
| coolant temp
| VAR_1007
| 1c
|
| ECU_AIRTEMP
| temperature 2
| Inlet pre turbo 1
| VAR_1001
| 1c
|
| ECU_ATMTEMP
| temperature 3
| Inlet pre turbo 2
| VAR_1002
| 1c
|
| ECU_FUEL
| Aux 3
| Lambda 2 short trim
| VAR_2002
| raw value
|
| ECU_GEAR
| Aux 13
| Fuel inj 8 PW
| VAR_2012
| raw value
|
| ECU_ENGOILT
| temperature 9
| Oil temp
| VAR_1008
| 1c
|
| ECU_TPS
| Aux 1
| Throttle position
| VAR_2000
| 0.10%
|
| ECU_BOOST_TFSI
| pressure 5
| Boost pressure
| VAR_3504
| 1kpa
|
| ECU_FUEL_P_L
| pressure 3
| Fuel pressure
| VAR_3502
| 0.1 bar
|
| ECU_FUEL_P_H
| pressure 4
| coolant pressure
| VAR_3503
| 0.1 bar
|
| ECU_LAMBDA
| misc 1
| Lambda 1
| VAR_4000
| 0.001
|
| ECU_ERR_CODE
| General variable 1
| General variable 1
| VAR_1250
| raw value
|
| ECU_RT_BOOST
| General variable 2
| General variable 2
| VAR_1251
| raw value
|
| ECU_ENGMOMENT
| General variable 3
| General variable 3
| VAR_1252
| 0.10%
|
| ECU_GASPERC
| General variable 4
| General variable 4
| VAR_1253
| 0.10%
|
| ECU_BRKPR
| General variable 5
| General variable 5
| VAR_1254
| 0.1 bar
|
| ECU_SPD2
| General variable 6
| General variable 6
| VAR_1255
| 0.1 km/h
|
| ECU_SPDAS
| General variable 7
| General variable 7
| VAR_1256
| 0.1 km/h
|
| ECU_FRLF_SPD
| General variable 8
| General variable 8
| VAR_1257
| 0.1 km/h
|
| ECU_FRRG_SPD
| General variable 9
| General variable 9
| VAR_1258
| 0.1 km/h
|
| ECU_RRLF_SPD
| General variable 10
| General variable 10
| VAR_1259
| 0.1 km/h
|
| ECU_RRRG_SPD
| General variable 11
| General variable 11
| VAR_1260
| 0.1 km/h
|
| ECU_YAWRATE
| General variable 12
| General variable 12
| VAR_1261
| deg/s
|
| ECU_STSPD
| General variable 13
| General variable 13
| VAR_1262
| deg/s
|
| ECU_STANG
| General variable 14
| General variable 14
| VAR_1263
| 0.1 deg
|
| ECU_BRK
| General variable 15
| General variable 15
| VAR_1264
| raw value
|
| ECU_CLUTCH
| General variable 16
| General variable 16
| VAR_1265
| raw value
|
| ECU_BOOST_TDI
| General variable 17
| General variable 17
| VAR_1266
| 1kpa
|
| ECU_ENG_MOM
| General variable 18
| General variable 18
| VAR_1267
| 0.10%
|
| ECU_AIR_FLOW
| General variable 19
| General variable 19
| VAR_1268
| raw value
|
| ECU_ASR_SW
| General variable 20
| General variable 20
| VAR_1269
| raw value
|
| ECU_MSR_SW
| General variable 21
| General variable 21
| VAR_1270
| raw value
|
| ECU_ABS_SW
| General variable 22
| General variable 22
| VAR_1271
| raw value
|
| ECU_EDS_SW
| General variable 23
| General variable 23
| VAR_1272
| raw value
|
| ECU_ESP_SW
| General variable 24
| General variable 24
| VAR_1273
| raw value
|
| ECU_COOL_ALARM
| General variable 25
| General variable 25
| VAR_1274
| raw value
|
| ECU_OILP_ALARM
| General variable 26
| General variable 26
| VAR_1275
| raw value
|
