Pectel ECUs
The Pectel data format is also used by MoTeC dashboards and some ECUs. For compatibility with the Race Technology interface the Pectel ECU should be configured to output the “STACK” data set.
The ECU must be set up to output data at 19200 baud with standard checksum. Start byte must be set to 0xA3.
| ECU Name
| Race Technology message
| Race Technology Default name
| Race Technology VAR number
| Resolution
|
| RPM
| Engine RPM
| RPM
| VAR_0010
| 25RPM
|
| Wheel Speed
| Aux 26
| Auxiliary 1
| VAR_2025
| 0.1kph
|
| Oil Pressure
| Pressure 2
| Oil Pressure
| VAR_3501
| 0.1 kPa
|
| Oil Temperature
| Temperature 9
| Oil Temperature
| VAR_1008
| 0.1°C
|
| Water Temperature
| Temperature 8
| Water Temperature
| VAR_1007
| 0.1°C
|
| Fuel Pressure
| Pressure 3
| Fuel Pressure
| VAR_3502
| 0.1 kPa
|
| Battery Voltage
| Misc 3
| Battery Voltage
| VAR_4002
| 0.01 V
|
| Throttle Angle
| Angle 1
| Throttle Angle
| VAR_3000
| 0.1°
|
| Intake Manifold Pressure
| Pressure 5
| Boost Pressure
| VAR_3504
| 0.1 kPa
|
| Intake Charge Temperature
| Temperature 1
| Temperature 1
| VAR_1000
| 0.1°C
|
| Exhaust Temperature
| Temperature 17
| Exhaust 1 Temp
| VAR_1016
| 0.1°C
|
| Lambda 1
| Misc 1
| Lambda 1
| VAR_4000
| 0.1 Lambda
|
| Fuel Temperature
| Temperature 25
| Aux 1
| VAR_1024
| 0.1°C
|
| Gear
| Aux 27
| Auxiliary 2
| VAR_2025
| Raw Value
|
| Counter
| Aux 28
| Auxiliary 3
| VAR_2026
| Raw Value
|
| Fuel Used
| Aux 29
| Auxiliary 4
| VAR_2027
| 0.1%
|
